TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Introduction
The TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch is an unmanaged Fast Ethernet switch designed to expand wired network connectivity in homes, offices, schools and small businesses. It provides 16 Ethernet ports, allowing several computers, printers, IP cameras and other network devices to share an existing wired network.
The TL-SF1016D is designed for easy installation with plug-and-play operation. Auto-Negotiation automatically detects whether connected devices operate at 10Mbps or 100Mbps, while Auto MDI/MDIX eliminates the need for special crossover cables.
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Price in Kenya
| Product |
Price |
| TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch |
KSh 4,000 |
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Key Specifications
| Specification |
Details |
| Model |
TL-SF1016D |
| Switch Type |
Unmanaged Fast Ethernet Switch |
| Number of Ports |
16 |
| Port Type |
RJ45 |
| Port Speed |
10/100Mbps |
| Auto-Negotiation |
Yes |
| Auto MDI/MDIX |
Yes |
| Switching Capacity |
3.2Gbps |
| Full Duplex |
Up to 200Mbps |
| MAC Address Table |
2K |
| Flow Control |
IEEE 802.3x |
| Transmission Method |
Store-and-Forward |
| Cooling |
Fanless |
| Power Saving |
Green Ethernet Technology |
| Power Supply |
External Power Adapter |
| Maximum Power Consumption |
Up to 3.2W |
| Dimensions |
200 × 142 × 40mm |
| Installation |
Desktop or Wall Mount |
| Casing |
Plastic |
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Performance
- Provides 16 Fast Ethernet ports for expanding wired network connections.
- Supports 10/100Mbps network speeds through Auto-Negotiation.
- Offers a 3.2Gbps switching capacity for efficient network traffic handling.
- Full-duplex operation provides up to 200Mbps bandwidth capability.
- IEEE 802.3x flow control helps manage network traffic and improve reliable data transmission.
- Store-and-forward technology helps ensure accurate packet delivery.
- Automatically adjusts connection speed according to the connected network device.
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Build Quality & Design
- Features a compact plastic housing suitable for desktop installations.
- Fanless construction provides quiet operation.
- Can be placed on a desk, shelf or other suitable networking surface.
- Supports wall mounting for more flexible installation.
- LED indicators make it easy to monitor power and port activity.
- Its 200 × 142 × 40mm design provides 16 network ports without requiring a large installation area.
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Connectivity & Compatibility
- Provides 16× 10/100Mbps RJ45 Ethernet ports.
- Auto MDI/MDIX eliminates the need for crossover cables.
- Compatible with computers, printers, IP cameras, servers and other Ethernet-enabled devices.
- Can be connected to a router to provide additional wired network connections.
- Supports IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards.
- Suitable for both home and business Ethernet networks.
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Ideal Use Cases
- Small office networks
- Home wired networks
- School computer laboratories
- Small business networks
- CCTV network installations
- Connecting multiple computers
- Network printer installations
- Connecting IP cameras
- Shops and workgroups
- Expanding an existing wired LAN
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Pros and Cons
| Pros |
Cons |
| 16 Ethernet ports |
Maximum port speed is 100Mbps |
| 3.2Gbps switching capacity |
No Gigabit Ethernet |
| Plug-and-play installation |
Unmanaged design has no advanced configuration |
| Auto MDI/MDIX support |
No PoE support |
| Fanless and quiet operation |
No Wi-Fi connectivity |
| Energy-efficient Green Ethernet technology |
No VLAN management |
| Desktop and wall mounting |
Designed mainly for basic wired networking |
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch FAQs
How many ports does the TP-Link TL-SF1016D have?
- The TL-SF1016D has 16 Ethernet ports.
What speed does the TP-Link TL-SF1016D support?
- It supports 10Mbps and 100Mbps Fast Ethernet connections.
Is the TP-Link TL-SF1016D a managed switch?
- No. It is an unmanaged switch designed for simple plug-and-play network expansion.
Does the TP-Link TL-SF1016D require configuration?
- No. Connect the switch to power and connect your Ethernet cables to start using it.
Does the TP-Link TL-SF1016D support Gigabit Ethernet?
- No. Its Ethernet ports support speeds of up to 100Mbps.
Can the TP-Link TL-SF1016D be used for CCTV?
- Yes. It can connect compatible Ethernet-based IP cameras. However, it does not provide PoE power.
Does the TP-Link TL-SF1016D support PoE?
- No. It is a standard Fast Ethernet switch and does not provide Power over Ethernet.
TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch Conclusion
The TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch is a practical solution for expanding wired networks where 10/100Mbps Fast Ethernet connectivity is sufficient. Its 16 ports, plug-and-play installation, Auto MDI/MDIX, 3.2Gbps switching capacity and energy-efficient operation make it suitable for homes, offices, schools and small businesses.
At KSh 4,000, the TP-Link TL-SF1016D provides an affordable way to add multiple wired Ethernet connections to an existing network without the complexity of a managed switch.
