Description
TP-Link MC110CS Single-Mode Media Converter Introduction
The TP-Link MC110CS Single-Mode Media Converter is a reliable networking device designed to convert between 100Mbps fiber optic and copper Ethernet connections. It allows network administrators to connect Ethernet equipment over single-mode fiber, making it suitable for extending network connections far beyond the typical distance supported by copper Ethernet cabling.
The MC110CS supports single-mode fiber transmission over distances of up to 20km when used with compatible fiber infrastructure. It features an SC/UPC fiber interface and a 10/100Mbps RJ45 Ethernet port, providing a straightforward way to connect switches, routers, computers and other Ethernet equipment to fiber networks.
With automatic duplex negotiation, Auto MDI/MDIX and flow-control features, the MC110CS is designed for easy deployment in offices, businesses, CCTV installations and building-to-building network connections.
TP-Link MC110CS Single-Mode Media Converter Price in Kenya
| Product |
Price |
| TP-Link MC110CS Single-Mode Media Converter |
KSh 4,500 |
TP-Link MC110CS Single-Mode Media Converter Key Specifications
| Specification |
Details |
| Model |
MC110CS |
| Product Type |
10/100Mbps Single-Mode Media Converter |
| Fiber Port |
1 × 100Mbps SC/UPC |
| Ethernet Port |
1 × 10/100Mbps RJ45 |
| Fiber Type |
Single-Mode Fiber |
| Fiber Standard |
100BASE-FX |
| Ethernet Standard |
100BASE-TX |
| Maximum Fiber Distance |
Up to 20km |
| Wavelength |
1310nm |
| Duplex Mode |
Half-Duplex / Full-Duplex |
| Auto-Negotiation |
Yes |
| Auto MDI/MDIX |
Yes |
| Flow Control |
IEEE 802.3x Full-Duplex / Backpressure Half-Duplex |
| Ethernet Cable |
Cat 3/4/5 for 10Mbps; Cat 5/5e for 100Mbps |
| LED Indicators |
PWR / Link/Act |
| Power Supply |
External Power Adapter |
| Maximum Power Consumption |
2.4W |
| Dimensions |
95 × 73 × 27mm |
| Operating Temperature |
0°C to 40°C |
| Certification |
FCC / CE / RoHS |
TP-Link MC110CS Single-Mode Media Converter Performance
- Provides Fast Ethernet connectivity at speeds of up to 100Mbps.
- Extends network connections over single-mode fiber for distances of up to 20km.
- Converts 100BASE-FX fiber signals to 100BASE-TX copper Ethernet.
- Automatic negotiation simplifies selection between half-duplex and full-duplex operation.
- IEEE 802.3x flow control helps manage traffic during full-duplex transmission.
- Half-duplex backpressure helps regulate network traffic when operating in half-duplex mode.
- Auto MDI/MDIX simplifies Ethernet cable connections.
- Full wire-speed forwarding helps maintain efficient data transmission.
- Suitable for long-distance network connections between buildings and remote network locations.
TP-Link MC110CS Single-Mode Media Converter Build Quality & Design
- Features a compact enclosure measuring approximately 95 × 73 × 27mm.
- Designed for convenient standalone desktop installation.
- Provides easily accessible SC/UPC fiber and RJ45 Ethernet interfaces.
- LED indicators make it easy to monitor power and network activity.
- Uses an external power adapter.
- Can also be installed in a compatible TP-Link MC1400 chassis.
- Compact construction makes it suitable for offices, network cabinets and other infrastructure locations.
TP-Link MC110CS Single-Mode Media Converter Connectivity & Compatibility
- Provides one 100Mbps SC/UPC fiber port.
- Provides one 10/100Mbps RJ45 Ethernet port.
- Designed for single-mode fiber connections using the 100BASE-FX standard.
- Supports 100BASE-TX copper Ethernet.
- Supports Auto MDI/MDIX on the RJ45 port.
- Compatible with Ethernet switches, routers, computers and other Fast Ethernet equipment.
- Can be deployed as a standalone converter or used with a compatible MC1400 chassis.
- Supports single-mode fiber transmission distances of up to 20km under suitable network conditions.
TP-Link MC110CS Single-Mode Media Converter Ideal Use Cases
- Extending Ethernet networks over single-mode fiber.
- Connecting offices or buildings through fiber.
- Business and enterprise network installations.
- CCTV and surveillance network infrastructure.
- Connecting remote network equipment over long distances.
- Converting copper Ethernet to single-mode fiber.
- Connecting switches and routers through fiber infrastructure.
- Campus and institutional networks.
- Network installations where copper Ethernet distance is insufficient.
- Long-distance 10/100Mbps Fast Ethernet connections.
TP-Link MC110CS Single-Mode Media Converter Pros and Cons
| Pros |
Cons |
| Supports single-mode fiber |
Maximum Ethernet speed is 100Mbps |
| Fiber transmission distance up to 20km |
Requires compatible single-mode fiber |
| SC/UPC fiber connector |
Not designed for Gigabit Ethernet |
| Supports 10/100Mbps RJ45 Ethernet |
Requires a compatible fiber connection at the other end |
| Auto-Negotiation and Auto MDI/MDIX |
Requires external power |
| Full-duplex and half-duplex support |
Limited to Fast Ethernet applications |
| IEEE 802.3x flow control |
Fiber performance depends on the network infrastructure |
| Compact standalone design |
Does not function as a network switch |
| Compatible with MC1400 chassis |
Limited management functionality |
TP-Link MC110CS Single-Mode Media Converter FAQs
What does the TP-Link MC110CS do?
- The MC110CS converts 100BASE-FX single-mode fiber signals to 100BASE-TX copper Ethernet signals and vice versa.
What type of fiber does the MC110CS support?
- It is designed for single-mode fiber using an SC/UPC connector.
What is the maximum transmission distance of the MC110CS?
- The MC110CS supports transmission distances of up to 20km over compatible single-mode fiber.
What Ethernet speed does the MC110CS support?
- It supports 10Mbps and 100Mbps Ethernet connections.
Does the MC110CS support Gigabit Ethernet?
- No. The MC110CS is designed for 10/100Mbps Fast Ethernet rather than Gigabit Ethernet.
What wavelength does the MC110CS use?
- It operates at a 1310nm wavelength.
Does the MC110CS support full duplex?
- Yes. It supports both half-duplex and full-duplex transfer modes with automatic negotiation.
Can the MC110CS operate without a chassis?
- Yes. It can operate as a standalone media converter. It can also be installed in a compatible TP-Link MC1400 chassis.
TP-Link MC110CS Single-Mode Media Converter Conclusion
The TP-Link MC110CS Single-Mode Media Converter is a practical solution for extending 10/100Mbps Ethernet networks over single-mode fiber. With support for transmission distances of up to 20km, an SC/UPC fiber interface and a 10/100Mbps RJ45 port, it is suitable for long-distance network installations.
Its Auto MDI/MDIX, automatic duplex negotiation, flow control and compact standalone design make it convenient for business networks, CCTV infrastructure and building-to-building connections. At KSh 4,500, the MC110CS is a suitable choice for reliable Fast Ethernet-to-single-mode-fiber conversion.
