Stock Status:
Condition: New
SKU : 8589M55
LC/APC connector provides a compact, precision optical connection for compatible multimode fiber equipment.
Multimode fiber is suitable for high-speed short- and medium-distance network connections.
OM3 50/125µm fiber supports high-bandwidth enterprise, campus and data-center networking applications.
2-meter length provides sufficient slack for routing and splicing inside fiber enclosures and distribution systems.
900µm tight-buffer construction makes the fiber easier to handle during splicing.
Low insertion loss of less than 0.2dB helps maintain optical signal quality.
Return loss above 35dB helps reduce unwanted optical reflections.
LSZH jacket provides low-smoke, zero-halogen characteristics for suitable indoor installations.
Zirconia ceramic ferrule supports precise fiber alignment.
Suitable for FTTH, enterprise networks, campus networks, data centers, ODFs and fiber patch panels
The Lightwave LW-PT-LCA-MM Fiber Pigtail, LC APC, MM, 2M is a 2-meter multimode fiber termination component designed for professional optical network installations. It features an LC/APC connector on one end and an unterminated fiber end intended for splicing to an incoming fiber cable.
The pigtail uses OM3 50/125µm multimode fiber and is suitable for data centers, enterprise LANs, campus networks and structured fiber infrastructure. Its compact 900µm tight-buffer construction provides flexibility during installation, while the factory-polished LC/APC connector helps provide consistent optical alignment.
| Product | Price in Kenya |
|---|---|
| Lightwave LW-PT-LCA-MM Fiber Pigtail, LC APC, MM, 2M | KSh 500 – KSh 5,500 |
| Specification | Details |
|---|---|
| Brand | Lightwave |
| Model | LW-PT-LCA-MM |
| Product Type | Fiber Optic Pigtail |
| Connector Type | LC/APC |
| Fiber Mode | Multimode |
| Fiber Type | OM3 |
| Core and Cladding | 50/125µm |
| Cable Length | 2 Meters |
| Buffer Diameter | 900µm |
| Jacket | LSZH |
| Ferrule Material | Zirconia Ceramic |
| Insertion Loss | <0.2dB |
| Return Loss | >35dB |
| Wavelengths | 850nm / 1300nm |
| Modal Bandwidth | Up to 2000MHz·km at 850nm |
| Minimum Bend Radius | Approximately 15mm |
| Tensile Strength | Up to 7kg |
| Mating Cycles | Up to 500 |
| Operating Temperature | -40°C to +75°C |
| Humidity | Up to 95% |
| Standards | IEC 61754-20, RoHS |
The detailed specifications above are based on current listings for the LW-PT-LCA-MM, while some listings differ on exact insertion-loss and fiber construction details.
OM3 multimode fiber provides high-bandwidth performance for suitable local-area optical networks.
50/125µm construction is widely used in high-speed multimode fiber infrastructure.
LC/APC termination provides accurate fiber alignment and helps reduce optical reflections.
Insertion loss below 0.2dB on listed specifications helps minimize signal loss at the connector.
Supports common multimode wavelengths of 850nm and 1300nm.
The 2-meter length provides additional routing flexibility inside racks, splice trays and distribution enclosures.
Factory termination helps provide consistent connector performance compared with field-polished connectors.
Actual network performance depends on the transceivers, splice quality, connector cleanliness and overall fiber installation.
Compact 900µm tight-buffered fiber is designed for easy handling during fiber termination.
LC connector construction is space-efficient for high-density fiber installations.
Angled Physical Contact polishing helps reduce reflected optical energy.
Zirconia ceramic ferrule provides accurate optical fiber alignment.
LSZH construction is suitable for many indoor environments where reduced smoke and halogen emissions are preferred.
The 2-meter length provides sufficient working slack for routing and splicing.
The unconnectorized end allows the pigtail to be fusion-spliced to a compatible multimode fiber cable.
Uses an LC/APC connector on one end.
Designed for compatible multimode fiber equipment.
The opposite fiber end is intended for splicing to an optical cable.
Suitable for compatible LC/APC adapters, patch panels and optical distribution equipment.
Can be integrated into enterprise LANs, campus networks and data-center fiber infrastructure.
Suitable for fiber termination within ODFs and splice trays.
The fiber mode, connector type and polish should match the connected optical equipment before installation.
Data centers: Suitable for multimode fiber termination and high-density optical infrastructure.
Enterprise networks: Useful for structured fiber connections between network equipment.
Campus networks: Supports optical links between buildings and network distribution points.
Fiber patch panels: Provides LC/APC termination for compatible multimode systems.
ODFs: Suitable for organized fiber termination and distribution.
Structured cabling: Helps create clean and manageable optical connections.
Telecommunications: Suitable for compatible multimode optical infrastructure.
Fiber installation and repairs: Useful for terminating or replacing individual fiber connections.
What type of fiber does the Lightwave LW-PT-LCA-MM use?
It uses multimode OM3 50/125µm fiber according to the detailed product listing.
What connector does the LW-PT-LCA-MM use?
It uses an LC/APC connector.
How long is the Lightwave LW-PT-LCA-MM?
The pigtail is 2 meters long.
What does APC mean on a fiber connector?
APC stands for Angled Physical Contact. The angled fiber end-face is designed to reduce back reflection and improve return-loss performance.
Is the LW-PT-LCA-MM a patch cord?
No. It is a fiber pigtail. One end has a factory-installed LC/APC connector, while the other end is left unconnectorized for splicing.
Can the LW-PT-LCA-MM be used for data centers?
Yes. The OM3 multimode fiber and compact LC connector make it suitable for compatible data-center and enterprise fiber infrastructure.
What is the insertion loss of the Lightwave LW-PT-LCA-MM?
The detailed listing specifies less than 0.2dB, while another listing gives a maximum of approximately 0.3dB.
What is the price of the Lightwave LW-PT-LCA-MM Fiber Pigtail in Kenya?
Based on the supplied price of KSh 500, the listed Kenya price range is KSh 500 – KSh 5,500.
| Pros | Cons |
|---|---|
| LC/APC factory-terminated connector | Requires splicing for complete fiber termination |
| OM3 multimode 50/125µm fiber | Not intended for single-mode fiber systems |
| 2-meter length | APC connector must match compatible equipment |
| Low insertion loss | Requires careful fiber handling |
| 900µm tight-buffer construction | Does not provide connectors on both ends |
| LSZH jacket | Requires compatible multimode optical equipment |
| Suitable for data centers and enterprise networks | Fusion-splicing equipment may be required |
The Lightwave LW-PT-LCA-MM Fiber Pigtail, LC APC, MM, 2M is a practical multimode fiber termination solution for data centers, enterprise networks, campus installations and structured optical infrastructure. Its OM3 50/125µm fiber, LC/APC connector, 2-meter length and compact 900µm construction make it suitable for organized fiber termination and splicing applications.
