Stock Status:
Condition: New
SKU : 8443M81
Brand – Grandstream
Model – GWN7664ELR
Type – Outdoor Long-Range Wi-Fi Access Point
Wi-Fi Standard – Wi-Fi 6 (802.11ax)
Wireless Technology – Dual-Band 4×4:4 MU-MIMO
Aggregate Wireless Throughput – Up to 6Gbps
2.4GHz Throughput – Up to 1.147Gbps
5GHz Throughput – Up to 4.8Gbps
Coverage Range – Up to 300 Meters
Concurrent Clients – Up to 512
Antennas – 8 Internal Antennas
Network Ports – 1 × 2.5GbE RJ45, 1 × 2.5Gbps SFP
PoE – 802.3at PoE+
Maximum Power Consumption – 24W
Weatherproof Rating – IP67
Mounting – Wall or Pole
The Grandstream GWN7664ELR Access Point is a high-performance outdoor Wi-Fi 6 access point designed for medium-to-large businesses and enterprise environments requiring long-range, high-capacity wireless connectivity. It delivers up to 6Gbps aggregate wireless throughput through dual-band 4×4:4 MU-MIMO and OFDMA technology, supports up to 512 concurrent Wi-Fi clients and provides coverage of up to 300 meters. Its IP67 weatherproof design, 2.5GbE RJ45 port, 2.5Gbps SFP port and PoE+ support make it suitable for campuses, warehouses, hospitals, schools and large commercial outdoor areas.
| Product | Price Range in Kenya |
|---|---|
| Grandstream GWN7664ELR Access Point | KSh 23,500 – 29,500 |
| Specification | Details |
|---|---|
| Brand | Grandstream |
| Model | GWN7664ELR |
| Type | Outdoor Long-Range Wi-Fi Access Point |
| Wi-Fi Generation | Wi-Fi 6 |
| Wi-Fi Standard | IEEE 802.11 b/g/n/ac/ax |
| Frequency Bands | 2.4GHz & 5GHz |
| MIMO | Dual-Band 4×4:4 MU-MIMO |
| OFDMA | Yes |
| 2.4GHz Throughput | Up to 1.147Gbps |
| 5GHz Throughput | Up to 4.8Gbps |
| Aggregate Wireless Throughput | Up to 6Gbps |
| Coverage Range | Up to 300m |
| Concurrent Clients | Up to 512 |
| Antennas | 8 Internal |
| 2.4GHz Antenna Gain | 5.5dBi |
| 5GHz Antenna Gain | 6.5dBi |
| Network Interface | 1 × 2.5GbE RJ45 |
| SFP Interface | 1 × 2.5Gbps SFP |
| PoE Standard | 802.3at PoE+ |
| Maximum Power Consumption | 24W |
| Weatherproof Rating | IP67 |
| Channel Bandwidth | 20/40/80/160MHz |
| SSIDs | 32 Total, 16 Per Radio |
| Security | WPA/WPA2/WPA3 |
| Mounting | Wall or Pole |
| Management | Embedded Controller, GWN.Cloud & GWN Manager |
| Dimensions | 260 × 310 × 59mm |
| Weight | 1.445kg |
| Operating Temperature | -30°C to 60°C |
| Operating Humidity | 10–90% Non-condensing |
Specifications are based on Grandstream's current product information and published technical documentation.
6Gbps Aggregate Wireless Throughput: The GWN7664ELR combines up to 1.147Gbps on 2.4GHz and 4.8Gbps on 5GHz, providing substantial wireless capacity for high-performance enterprise and outdoor networks.
Dual-Band 4×4:4 MU-MIMO: Four spatial streams on each wireless band allow the access point to efficiently serve multiple compatible devices while maintaining strong wireless capacity.
Wi-Fi 6 and OFDMA: Wi-Fi 6 technology with OFDMA improves spectrum efficiency and helps the access point handle simultaneous transmissions more efficiently in environments with many connected clients.
512 Concurrent Clients: Support for up to 512 concurrent Wi-Fi client devices makes the GWN7664ELR suitable for high-density deployments such as campuses, warehouses, hospitals and large commercial facilities.
IP67 Weatherproof Construction: The IP67-rated enclosure provides protection against dust and water ingress, making the access point suitable for demanding outdoor installations when properly mounted.
2.5GbE RJ45 Connectivity: The 2.5Gbps Ethernet port provides high-speed wired connectivity and supports PoE+ power delivery for simplified network installation.
2.5Gbps SFP Connectivity: The dedicated 2.5Gbps SFP port provides a fiber connectivity option for deployments requiring high-speed links between the access point and network infrastructure.
Eight Internal Antennas: The eight internal antennas are designed to provide broad wireless coverage while maintaining the weather-resistant construction of the outdoor access point.
Enterprise Wireless Networks: Suitable for businesses requiring high-capacity Wi-Fi coverage across large facilities and outdoor areas.
Campus Wi-Fi: The 300-meter coverage capability makes it suitable for schools, universities, corporate campuses and institutional compounds.
Warehouse Networks: Can provide high-speed wireless connectivity across large warehouse and industrial environments where broad coverage and client capacity are important.
Hospital and Healthcare Facilities: Suitable for large healthcare environments requiring managed outdoor and extended-area wireless connectivity.
Commercial Outdoor Wi-Fi: Can be deployed around commercial buildings, compounds and other outdoor spaces requiring reliable Wi-Fi 6 connectivity.
Centralized Wi-Fi Management: The embedded controller can manage up to 50 local GWN access points, while GWN.Cloud and GWN Manager provide cloud and on-premises management options.
| Pros | Cons |
|---|---|
| Up to 6Gbps aggregate wireless throughput | Higher specifications may exceed small network requirements |
| Wi-Fi 6 technology | Actual coverage varies according to environment |
| 4×4:4 MU-MIMO and OFDMA | Requires PoE+ infrastructure or compatible power |
| Supports up to 512 concurrent clients | Larger and heavier than standard indoor APs |
| Up to 300m coverage | Outdoor installation requires proper positioning |
| 2.5GbE RJ45 and 2.5Gbps SFP | Higher-end deployment may require multi-gig network infrastructure |
| IP67 weatherproof construction | Primarily designed for larger deployments |
The Grandstream GWN7664ELR is a high-performance outdoor Wi-Fi 6 access point designed for long-range and high-density enterprise wireless deployments.
It supports up to 6Gbps aggregate wireless throughput, with up to 1.147Gbps on 2.4GHz and 4.8Gbps on 5GHz.
The GWN7664ELR provides coverage of up to 300 meters, although actual range varies according to environmental conditions, obstacles, interference and installation.
The access point supports up to 512 concurrent Wi-Fi client devices.
Yes. It supports 802.3at PoE+ and has a maximum power consumption of 24W.
Yes. The GWN7664ELR is designed for outdoor deployment and features IP67 weatherproof and dust protection, along with an operating temperature range of -30°C to 60°C.
The Grandstream GWN7664ELR Access Point is a high-capacity Wi-Fi 6 solution designed for demanding long-range wireless deployments. Its 6Gbps aggregate throughput, 4×4:4 MU-MIMO, support for 512 clients, 300-meter coverage, 2.5GbE RJ45, 2.5Gbps SFP and IP67 weatherproof construction make it a strong choice for enterprise campuses, warehouses, hospitals, schools and commercial outdoor networks.
