Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Overview
The Dahua XVR5108HS Penta-brid DVR is a powerful hybrid surveillance recorder designed for flexible CCTV system integration. It supports multiple camera technologies including HDCVI, AHD, TVI, CVBS, and IP cameras, making it suitable for both upgrading existing analog systems and building modern IP-based surveillance setups.
It features 8 BNC analog inputs, supports up to 24 IP camera channels (with expansion), and can handle up to 6MP resolution per IP camera. The device also supports smart video compression and high-definition output via HDMI and VGA up to 4K resolution.
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Price in Kenya
| Product |
Price (KES) |
| Dahua XVR5108HS Penta-brid DVR |
18,500 – 19,500 KES |
Pricing varies depending on supplier, HDD inclusion, and installation package.
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Specifications
| Specification |
Details |
| Model |
XVR5108HS |
| Channels |
8 BNC analog inputs |
| IP Camera Support |
Up to 24 IP channels (max 6MP per camera) |
| Video Input Types |
HDCVI / AHD / TVI / CVBS / IP (Penta-brid support) |
| Compression |
H.265 / H.264 |
| HDMI Output |
Up to 4K resolution |
| VGA Output |
Supported |
| Network Interface |
1 × RJ45 LAN port |
| USB Ports |
2 × USB |
| Audio Input/Output |
1-channel audio in / 1-channel audio out |
| Two-way Audio |
Supported (talk function) |
| Storage |
1 × SATA HDD slot (supports up to 16TB HDD) |
| Smart Features |
Motion detection, smart search (model dependent) |
| Power Supply |
12V DC |
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Connectivity
- 8 × BNC camera inputs supporting HDCVI / AHD / TVI / CVBS analog cameras
- Supports up to 24 IP cameras (maximum 6MP per IP camera) via network connection
- 1 × RJ45 Ethernet LAN port for internet access, remote viewing, and IP camera integration
- 1 × HDMI output supporting up to 4K resolution display for live view and playback
- 1 × VGA output for connection to standard monitors and legacy display systems
- 2 × USB ports for mouse control, firmware updates, and video backup/export
- 1 × audio input channel (RCA) for external microphone connection
- 1 × audio output channel (RCA) for external speaker or sound system
- Supports two-way audio (talk function) for live communication through the system
- 1 × SATA HDD slot supporting up to 16TB storage capacity
- Hybrid Penta-brid support (HDCVI / AHD / TVI / CVBS + IP cameras) for flexible system integration
- Network connectivity enables mobile app access and remote CCTV monitoring
- HDMI + VGA dual video output for multi-display setup compatibility
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Performance
- Supports both analog and IP camera systems for flexible upgrades
- Handles up to 6MP IP camera resolution for clear surveillance detail
- 8 BNC inputs allow stable connection of multiple analog cameras
- Up to 24 IP camera channels support system expansion
- 4K HDMI output delivers sharp live and playback viewing
- Efficient compression reduces HDD storage usage
- Stable LAN connectivity ensures reliable remote access
- Two-way audio enables live communication monitoring
- Supports up to 16TB storage for long-term recording
- Ideal for scalable CCTV system upgrades
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Features
- 8-channel analog BNC inputs
- Supports HDCVI / AHD / TVI / CVBS / IP (Penta-brid)
- Up to 24 IP camera channels support
- Maximum 6MP IP camera resolution
- 4K HDMI + VGA output support
- 1 × RJ45 network port
- 2 × USB ports
- 1-channel audio input and output
- Two-way audio talk support
- 1 SATA HDD slot (up to 16TB)
- Remote viewing via mobile and PC
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Design & Build
- Compact 1U DVR design for flexible installation
- Durable metal casing for continuous operation
- Rear port layout for clean cabling setup
- Front USB access for quick backup
- Designed for 24/7 surveillance environments
- Efficient cooling system for stable performance
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Use Cases
- Home security systems
- Business and office surveillance
- Retail shop monitoring
- Warehouses and storage facilities
- Schools and institutions
- Mixed analog + IP CCTV upgrades
- Commercial security installations
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Pros and Cons
| Pros |
Cons |
| Supports analog + IP camera integration |
Requires technical setup for IP expansion |
| Up to 24 IP camera channels |
Only 1 HDD slot |
| 4K HDMI output support |
No built-in Wi-Fi |
| Multi-format Penta-brid compatibility |
Advanced features depend on firmware |
| Large storage support up to 16TB |
IP features may vary by configuration |
| Two-way audio support |
Slight learning curve for beginners |
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR FAQs
How many cameras does it support?
It supports 8 analog cameras and up to 24 IP cameras.
Does it support 4K display?
Yes, via HDMI output.
What is the maximum storage supported?
Up to 16TB SATA HDD.
Can it mix analog and IP cameras?
Yes, it is a Penta-brid DVR.
Does it support audio?
Yes, with 1 audio input and 1 output plus two-way talk.
Dahua XVR5108HS Penta-brid 5MP 6 Channel DVR Conclusion
The Dahua XVR5108HS Penta-brid DVR is a flexible and scalable surveillance recorder designed for hybrid CCTV systems. With support for analog and IP cameras, up to 24 IP channels, 6MP resolution, 4K HDMI output, and large storage capacity, it is ideal for modern security installations in Kenya.
