The AW-CMC2166-6 Conventional Manual Call Point is a fire alarm emergency activation device designed for conventional fire alarm systems in homes, offices, schools, factories, warehouses, and commercial buildings. It allows users to manually trigger a fire alarm during emergencies using its PUSH IN/PULL DOWN activation mechanism.
The device is built for high reliability, easy installation, and stable operation with conventional fire alarm control panels. It supports both flush and surface mounting options and features a resettable design that allows reuse after activation without replacing glass components.
AW-CMC2166-6 Conventional Manual Call Point Price in Kenya
| Product |
Price |
| AW-CMC2166-6 Conventional Manual Call Point |
KSh 1,500 – KSh 4,500 |
AW-CMC2166-6 Conventional Manual Call Point Specifications Table
| Specification |
Details |
| Model |
AW-CMC2166-6 |
| Product Type |
Conventional Manual Call Point |
| System Type |
Conventional Fire Alarm System |
| Operating Voltage |
9V – 28V DC |
| Rated Voltage |
24V DC |
| Alarm Current |
10mA – 45mA |
| Standby Current |
≤60μA |
| Connection Type |
Two-wire connection |
| Mounting Type |
Flush or Surface Mount |
| Reset Method |
Resettable with key |
| Activation Type |
PUSH IN / PULL DOWN |
| Material |
ABS Plastic |
| Operating Temperature |
-10°C to 50°C |
| Humidity Range |
10% – 93% RH |
| Dimensions |
140 × 105 × 45 mm |
| Weight |
Approx. 220g |
AW-CMC2166-6 Conventional Manual Call Point Features
- Manual fire alarm activation switch
- PUSH IN / PULL DOWN emergency operation
- Resettable design using reset key
- Compatible with conventional fire alarm panels
- Two-wire connection support
- Available for flush or surface mounting
- High reliability fire safety design
- Easy installation process
- Durable ABS plastic housing
- Visible activation indication
- Tamper-resistant construction
- Suitable for commercial and residential fire systems
AW-CMC2166-6 Conventional Manual Call Point Performance
- Provides fast manual fire alarm activation
- Reliable emergency response functionality
- Stable operation with conventional fire panels
- Quick alarm triggering during emergencies
- Resettable mechanism reduces replacement costs
- Performs reliably in commercial installations
- Supports long-term fire safety operation
- Simple and responsive PUSH IN / PULL DOWN mechanism
- Low standby current consumption
- Designed for continuous fire protection systems
- Suitable for schools, offices, warehouses, and factories
AW-CMC2166-6 Conventional Manual Call Point Connectivity
- Compatible with conventional fire alarm control panels
- Supports standard two-wire connection
- Operates on 9V – 28V DC systems
- Optimized for 24V DC fire alarm systems
- Easy integration with fire alarm zones
- Supports indoor fire alarm wiring systems
- Compatible with smoke and heat detector systems
- Suitable for commercial and residential installations
AW-CMC2166-6 Conventional Manual Call Point Build Quality
- Durable ABS plastic enclosure
- Compact and lightweight construction
- Designed for long-term fire safety installations
- Strong wall mounting structure
- Available for flush and surface mounting
- Resistant to daily wear and usage
- Resettable mechanism improves durability
- Designed for indoor commercial and residential environments
AW-CMC2166-6 Conventional Manual Call Point Use Cases
- Office fire alarm systems
- School and university fire protection
- Commercial building fire safety
- Warehouse emergency systems
- Factory fire alarm installations
- Residential apartment fire systems
- Hotel and hospitality safety systems
- Retail shop fire protection
AW-CMC2166-6 Conventional Manual Call Point Pros and Cons
| Pros |
Cons |
| Reliable manual fire alarm activation |
Requires compatible fire alarm panel |
| Resettable without replacing glass |
Wired installation required |
| Easy installation process |
Conventional system only |
| Supports flush and surface mounting |
No wireless functionality |
| Low standby power consumption |
Indoor-focused installation |
| Durable ABS construction |
Professional setup may be required |
AW-CMC2166-6 Conventional Manual Call Point FAQs
What is the AW-CMC2166-6 used for?
It is used to manually trigger a fire alarm during emergency situations in conventional fire alarm systems.
How does the manual call point work?
The device activates using a PUSH IN / PULL DOWN handle mechanism that sends an alarm signal to the fire alarm control panel.
Can the AW-CMC2166-6 be reset after activation?
Yes. It can be reset using a special key without replacing glass components.
Is it compatible with all fire alarm systems?
The AW-CMC2166-6 is specifically designed for conventional fire alarm systems.
Does it support surface mounting?
Yes. It supports both flush mounting and surface mounting installation options.
What voltage does the device support?
It operates within a voltage range of 9V to 28V DC and is commonly used with 24V DC systems.
AW-CMC2166-6 Conventional Manual Call Point Conclusion
The AW-CMC2166-6 Conventional Manual Call Point is a dependable fire safety device designed for quick emergency alarm activation in commercial and residential buildings. Its resettable operation, durable construction, simple installation, and compatibility with conventional fire alarm systems make it suitable for a wide range of fire protection applications.
For users in Kenya looking for a reliable and cost-effective manual fire alarm activation device, the AW-CMC2166-6 provides dependable performance and long-term fire safety reliability.
